6420093-5 CHRONOS CHRONOS Digital Clock / MAX Power USB Charge
$969.00
Part Number: 6420093-5
Model Number: CH93MAX
Manufacturer: Mid-Continent Instruments and Avionics
Frequently Bought Together
Why Pilots Trust AVIA Avionics
Enjoy fast UPS, USPS, or DHL delivery on qualifying orders.
We use DHL or UPS for worldwide shipments. Some shipments may require special processing.
Sales tax only applies where required by law.
Strong customer service with fast response times.
Description
Product Description
Combine time keeping and USB charging power in one essential unit with the CHRONOS CH93MAX digital clock. MAX Power USB-C PD and USB-A charging ports can simultaneously charge two devices. The TSO-certified CH93MAX offers 8 modes and is an ideal replacement for older, single-function clocks.
Benefit
- Six-digit, seven-segment LED clock
- Eight modes: Local Time, UTC / Zulu Time, Flight Timer, Countdown Timer, Stopwatch, Volts, OAT and Secondary Air Temp
- Clock settings include 12- or 24-hour mode and seconds On or Off
- Manual and automatic lighting control with programmable dimming curves
- Internal, field-replaceable battery maintains time and Flight Timer memory without aircraft power
- Compact, 2-inch size fits standard panel cutout
- 15 watts / 3 amps and 60 watts / 3 amps USB power per port
- Compatible with Apple, Android and other USB devices
- Protects itself and the charging device from short circuit, power surges and over-current potential
- Designed and built in Wichita, Kansas, USA
- Two-year limited warranty
Specifications
Power Input
22–32 VDC; 84 W maximum
3.0 A @ 28 VDC
USB Power Output
5 - 20 VDC (variable); 15 W, 3.0 A and 60 W, 3.0 A per port
Clock Accuracy
±0.5 seconds in 24 hours, ± 3 minutes per year
Weight
5.0 oz (0.3 lbs)
Modes
Local Time, UTC / Zulu Time, Flight Timer, Countdown Timer, Stopwatch, Volts, OAT and Secondary Air Temp
Operating Temp
-40ºC to 70ºC (-40ºF to 158ºF)
Altitude
55,000 feet
Mounting
Rear-panel mounted, (4) #6 screws
Dimensions
2.39″W x 2.39″H x 1.22″D
Connector Kit
MCIA P/NÂ 9018178-1
USB Interface
Dual USB-A/USB-C PD
Case
Anodized aluminum, black
Certification
FAA TSO certified to C71
EASA ETSO certified to C71
RTCA DO-160G qualified
