6430120-2 DC-to-DC Voltage Converter
$766.00
Part Number: 6430120-2
Model Number: TC120
Manufacturer: Mid-Continent Instruments and Avionics
Technical Description: 24–32 VDC in, 5–24 VDC out, 120 watts, With remote on/off feature
Frequently Bought Together
Why Pilots Trust AVIA Avionics
Enjoy fast UPS, USPS, or DHL delivery on qualifying orders.
We use DHL or UPS for worldwide shipments. Some shipments may require special processing.
Sales tax only applies where required by law.
Strong customer service with fast response times.
Description
Supply 120 watts of 5 – 18 volt power to electronic equipment, lighting and cabin accessories with the True Blue Power TC120 aircraft voltage converter. The TSO-certified 6430120-2 is available with a remote on/off feature and is designed to save space and reduce weight.
Converter Comparison Chart
Features
- Supplies 120 watts of 5 to 24-volt power to electronic equipment, including USB charging ports, lighting and cabin accessories
- Compact design — lighter and smaller than competing units
- Lightweight — 0.6 lbs
- Remote On/Off
- 120 watts output power
- >90% efficiency
- Input Voltage: 24 – 32 VDC
- Input Current: 5.0 A Nominal
- Output Voltage: 5 – 24 VDC
- Input transient, overload, and short-circuit protection
- Rated from –65°F to +160°F (-55°C to +70°C)
- FAA TSO-C71 certified and RTCA DO-160G qualified
- Designed and built in Wichita, Kansas, USA
- Two-year limited warranty
Specifications
Input Voltage
24 – 32 VDC
Input Current
5.0 A Nominal
Output Voltage
5 – 24 VDC
Output Power
120 watts
Efficiency
>90%
Weight
0.65 lbs (0.29 kg)
Altitude
55,000 ft
Temperature
-65°F to +160°F (-55°C to +70°C)
Protection
Input transient, overload, short-circuit protection
Mating Connector
MS3106A-14S-5S
Case
Anodized aluminum, blue
Certification
FAA TSO-C71 certified
RTCA DO-160G qualified
