?? 6430271-1 Lithium-ion Aircraft Battery ??
Part Number: 6430271-1
Model Number: TB270V
Manufacturer: Mid-Continent Instruments and Avionics
Technical Description: 270 VDC, 2.5 Ah, Lithium-ion
Frequently Bought Together
Why Pilots Trust AVIA Avionics
Enjoy fast UPS, USPS, or DHL delivery on qualifying orders.
We use DHL or UPS for worldwide shipments. Some shipments may require special processing.
Sales tax only applies where required by law.
Strong customer service with fast response times.
Description
No product description currently available.
Benefits
- 2.5 amp-hour nominal at 23°C/73°F
- Weighs 22 lbs. — up to 60% less than lead-acid and NiCad solutions
- Advanced NanoPhosphate® lithium-ion cell chemistry
- Higher voltage during engine start — Less wear, less maintenance and increased useful life
- Superior high-temperature and cold-weather performance from -40°C to +70°C (-40°F to +158°F)
- Automatic internal heater
- Overcharge, over-discharge, over-current, short circuit, over-temperature, under-temperature and charge current limiting protection
- Built-in Test (BIT) Indicator communicates real-time state-of-charge and state-of-health
- On-condition maintenance
- Designed and built in Wichita, Kansas, USA
Specifications
Capacity
50 amp-hour nominal (at 23°C/73°F)
Charge Voltage
28 VDC nominal
Output Voltage
26.4 VDC nominal
Output Current
460A continuous (1500A max)
Technology
Advanced NanoPhosphate® lithium-ion cell chemistry
Energy Density
66.3 Wh/kg (83.1 Wh/liter)
Charge Current Limiting
Programmable up to 8C or unlimited
Operating Temperature
-40°C to +70°C (-40°F to +158°F)
Weight
43.9 lbs. (19.9 kg)
Dimensions
10.0”L x 9.6”W x 10.1”H
Configuration
21P8S; 7 parallel x 8 in series x 3
Battery Life Expectancy
8 years (average)
Maintenance
On-condition
Case
Anodized aluminum, blue
Certification
FAA TSO-C179b (Class A-4B)
RTCA DO-311A
RTCA DO-160G
RTCA DO-178C DAL A
UNDOT/IATASpecifications
Capacity
2.5 amp-hour nominal (at 23°C/73°F)
Charge Voltage
288 VDC
Output Voltage
264 VDC nominal
Output Current
70A continuous (120A max)
Technology
Advanced NanoPhosphate® lithium-ion cell chemistry
Energy Density
63.1 Wh/kg (80.7 Wh/liter)
Charge Current Limiting
Programmable up to 20A or unlimited
Operating Temperature
-40°C to +70°C (-40°F to +158°F)
Weight
22 lbs. (10 kg)
Dimensions
13.25"L x 11.0"W x 3.3"H
Configuration
1P80S; 1 parallel x 80 series
Battery Life Expectancy
8 years (average)
Maintenance
On-condition
Case
Anodized aluminum, blue
