Integrated Battery Back-up System (IBBS)

Name: Integrated Battery Back-up System (IBBS)
Brand: TCW Technologies
SKU: 6033
Availability: InStock

Price range: $28.62 through $1,767.67

The Integrated Battery Back-up System (IBBS) provides an engineered solution to enable an endurance bus for critical loads found in aircraft. The IBBS system provides back-up power to critical electronic loads such as EFIS, GPS, Autopilots and engine monitoring systems.

IBBS is available in 6 different models, including three FAA Certified models. Installation parts and accessories are available to complete your installation, such as a dsub connector or full installation kit, through the Accessories tab or by choosing from the model list below.

Frequently Bought Together

Model

Clear

Add to compare

Add to wishlist

Why Pilots Trust AVIA Avionics

Free Ground Shipping Over $399

Enjoy fast UPS, USPS, or DHL delivery on qualifying orders.

Shipping Worldwide

We use DHL or UPS for worldwide shipments. Some shipments may require special processing.

No Sales Tax

Sales tax only applies where required by law.

5 Star Service, White Glove

Strong customer service with fast response times.

Talk to a Real Aviation Expert

Need help placing an order?

Description

Integral to the IBBS is a lithium-iron-phosphate battery pack and a matched charging system to ensure the battery is properly charged and maintained. The system includes switching circuitry to provide a stable source of output power during both normal and emergency operations. The IBBS system also provides signals to other equipment such as EFIS systems to communicate the operating state of the back-up bus as well as the state of the battery.

The IBBS system connects to the standard aircraft power bus and provides an output to critical equipment that requires back-up power. Additionally, the IBBS system provides surge and sag protection for connected equipment, allowing operation of critical equipment during engine starting.

The IBBS system is suitable for use with equipment such as Garmin GNS and GTN series navigators, G3X series of avionics, Grand Rapids Technologies EFIS systems, Advanced Flight Systems EFIS, Dynon EFIS, and MGL EFIS, TruTrak Autopilots and EFIS, and Trio Autopilots.

IBBS products are protected by US Patent 8,189,305

Experimental Models:

12 volt, 3 amp-hour, Li-Fe-PO4 Integrated Battery Back-up System (IBBS-12V-3AH)
12 volt, 6 amp-hour, Li-Fe-PO4 integrated Battery Back-up System (IBBS-12V-6AH)
24 volt, 3 amp-hour, Li-Fe-PO4 Integrated Battery Back-up System (IBBS-24V-3AH)

Installation Kit:

Experimental IBBS Install Kit (IBBS-HARN-LiFe)

Includes wiring harness and dsub connector

FAA Certified Models:

12 volt, 3 amp-hour, Li-Fe-PO4 Integrated Battery Back-up System (IBBS-12V-3AH-CRT-V)
12 volt, 6 amp-hour, Li-Fe-PO4 Integrated Battery Back-up System (IBBS-12V-6AH-CRT-V)
24 volt, 3 amp-hour, Li-Fe-PO4 Integrated Battery Back-up System (IBBS-24V-3AH-CRT-V)

FAA Certified Installation Kit:

Certified IBBS Install Kit for 12 volt models (IBBS-CRT-INSTALL-Kit-12V)
Certified IBBS Install Kit for 24 volt models (IBBS-CRT-INSTALL-Kit-24V)

Includes wiring harness, LED indicator, switch, mounting hardware and STC data package with authorization letter

FAA Certified Data Package:

STC Data Package with Authorization Letter (STC-AML-Data)

Weight	2 lbs
Dimensions	9 × 6 × 5 in

Integrated Battery Back-up System Specifications

Non-Certified

	IBBS-12V-3AH	IBBS-12V-6AH	IBBS-24V-3AH
*Input Voltage :**	13 – 15 volts DC	13 – 15 volts DC	26 – 32 volts DC
Transition Voltage:**	10.5 – 11.5 volts	10.5 – 11.5 volts	21 – 23 volts
Input Current:	2.5 amps max continuous on main input for charging	4.0 amps max continuous on main input for charging	3.0 amps max continuous on main input for charging
Pass-thru Current:	5 amps continuous, 10 amps peak (30 seconds)	8 amps continuous, 12 amps peak (30 seconds)	5 amps continuous, 10 amps peak (30 seconds)
Output Voltage:	10 – 14 volts DC during back-up operation	10 – 14 volts DC during back-up operation	22 – 29 volts DC during back-up operation
Output Current:	5 amps continuous, 10 amps peak for radio transmissions and transient loads	8 amps continuous, 12 amps peak for radio transmissions and transient loads (30 second duration max)	5 amps continuous, 10 amps peak for radio transmissions and transient loads (30 second duration max)
Battery:	Internal sealed Li-Fe-PO4	Internal sealed Li-Fe-PO4	Internal sealed Li-Fe-PO4
Charger:	Integral high-performance fast charger	Integral high-performance fast charger	Integral high-performance fast charger
Surge Protection:	34 volt active clamp, 1500 w 10/1000uS waveform	34 volt active clamp, 1500 w 10/1000uS waveform	51 volt active clamp, 1500 w 10/1000uS waveform
Wiring:	15 pin male D-sub on product	15 pin male D-sub on product	15 pin male D-sub on product
Enclosure:	Aluminum 7.7” x 2.3” x 1.6”	Aluminum 7.7” x 2.3” x 2.75”	Aluminum 7.7” x 2.3” x 2.75”
Weight:	18 oz.	34 oz.	34 oz.
Temperature Range:	Operating: -10° C to 60° C Charging 0° C to 40° C	Operating: -10° C to 60° C Charging 0° C to 40° C	Operating: -10° C to 60° C Charging -20° C to 40° C
Connector:	Standard density 15 pin male D-sub on product	Standard density 15 pin male D-sub on product	Standard density 15 pin male D-sub on product

*Minimum input voltage for battery recharging
**Transition voltage is the voltage level on the input that causes the system to provide output power via the internal back-up battery
For Experimental Aircraft Only, not TSO’d

Integrated Battery Back-up System Specifications

	IBBS-12V-3AH-CRT-V	IBBS-12V-6AH-CRT-V	IBBS-24V-3AH-CRT-V
TSO Certification:	TSO-C179(b)	TSO-C179(b)	TSO-179(b)
Input Voltage:	13.5 – 15 volts DC for battery charging	13.5 – 15 volts DC for battery charging	26 – 32 volts DC for battery charging
*Transition Voltage:**	10.5 – 11.5 volts	10.5 – 11.5 volts	21 – 23 volts
Input Current:	2.5 amps max on main input for charging	4.0 amps max on main input for charging	3.0 amps max on main input for charging
Pass-thru Current:	5 amps continuous, 10 amps peak (30 seconds)	8 amps continuous, 12 amps peak (30 seconds)	5 amps continuous, 10 amps peak (30 seconds)
Output Voltage:	10 – 14 volts DC during back-up operation	10 -14 volts DC during back-up operation	22 – 29 volts DC during back-up operation
Output Current:	5 amps continuous, 10 amps peak for radio transmissions and transient load (30 second duration max)	8 amps continuous, 12 amps peak for radio transmissions and transient load (30 second duration max)	5 amps continuous, 10 amps peak for radio transmissions and transient loads (30 second duration max)
Battery:	Internal sealed Li-Fe-PO4, nominal 12.8 volts	Internal sealed Li-Fe-PO4, nominal 12.8 volts	Internal sealed Li-Fe-PO4, nominal 25.6 volts
Charger:	Integral high-performance fast charger with cell balancing and thermal monitoring	Integral high-performance fast charger with cell balancing and thermal monitoring	Integral high-performance fast charger with cell balancing and thermal monitoring
Surge Protection:	34 volt active clamp, 1500w 10/1000uS waveform	34 volt active clamp, 1500w 10/1000uS waveform	51 volt active clamp, 1500 w 10/1000uS waveform
Wiring:	15 pin male D-dub on product	15 pin male D-sub on product	15 pin male D-sub on product
Enclosure:	Cast aluminum, sealed and externally vented; 11.9” x 3.3” x 3.2”	Cast aluminum, sealed and externally vented; 11.9” x 3.3” x 3.2”	Cast aluminum, sealed and externally vented; 11.9” x 3.3” x 3.2”
Weight:	4.25 lb.	5.25 lb.	5.25 lb.
Temperature Range:	Operating: -40° C to 60° C Charging -40° C to 40° C	Operating: -40° C to 60° C Charging -40° C to 40° C	Operating: -40° C to 60° C Charging -40° C to 40° C
Connector:	Standard density 15 pin D-sub, male on product	Standard density 15 pin D-sub, male on product	Standard density 15 pin male D-sub on product
