MD200-707 Course Deviation Indicator
$3,625.00
Part Number: MD200-707
Model Number: MD200
Manufacturer: Mid-Continent Instruments and Avionics
Technical Description: 3″, Lighted, Glideslope and course datum
Frequently Bought Together
Why Pilots Trust AVIA Avionics
Enjoy fast UPS, USPS, or DHL delivery on qualifying orders.
We use DHL or UPS for worldwide shipments. Some shipments may require special processing.
Sales tax only applies where required by law.
Strong customer service with fast response times.
Description
The MD200-707, 3-inch Course Deviation Indicator (CDI), provides the highest quality for primary or secondary GPS/VOR navigation. This TSO-certified aircraft CDI features all-metal construction with stainless steel ball bearings in critical areas, demonstrating proven reliability and performance in a wide variety of aircraft.
Features
- Fits standard 3 1/8” panel cutout
- All-metal construction with stainless steel ball bearings in critical areas
- Deviation bars/pointers hide from view when invalid
- LED annunciations for NAV, GPS, VLOC and To/From indication
- True OBS course resolver output
- Compatible with WAAS GPS receivers
- Pin-for-pin replacement for all legacy MD200 models
- Optional course datum synchro output (MD200-707)
- High-quality d-sub connectors included with gold-plated pins
- FAA TSO and ETSO certified for use with all GPS and VOR systems
- Designed and built in Wichita, Kansas, USA
- One-year limited warranty
Specifications
Voltage Input
12 – 32 VDC
Current Input
0.2 amps max
Lighting
5V, 14V, or 28V automatic photocell dimming of annunicators
Cutout
Standard 3 1/8” round
Weight
1.4 lbs
Temperature
–55°C to +70°C (–67°F to +158°F)
Altitude
0 to 55,000 ft
Humidity
95% non-condensing
Vibration
DO-160B, Cat. M and N
Certification
FAA TSO certified to C34e, C36e, C40c
EASA ETSO certfied to C34e, C36e, 2C40c
RTCA DO-1606 qualified
Mounting
Panel, rear mount
Connector(s)
25-pin male D-Subminiature
9-pin male D-Subminiature
Mating Connector(s)
25-pin female D-Subminiature (included)
9-pin female D-Subminiature (included)
