MD23-104 Digital Annunciation Control Unit
$2,500.00
Part Number: MD23-104
Model Number: MD23
Manufacturer: Mid-Continent Instruments and Avionics
Frequently Bought Together
Why Pilots Trust AVIA Avionics
Enjoy fast UPS, USPS, or DHL delivery on qualifying orders.
We use DHL or UPS for worldwide shipments. Some shipments may require special processing.
Sales tax only applies where required by law.
Strong customer service with fast response times.
Description
Product Description
The TSO-certified MD23-104 Digital Annunciation Control Unit monitors and displays True Blue Power® Gen5 Lithium-ion Battery parameters. It provides status, state of charge, state of health, volts, amps, temperature, remaining life and fault data. Night Vision Imaging System (NVIS) compatible versions are available.
Benefits
- Monitors and displays True Blue Power® Gen5 lithium-ion battery parameters
- Provides status, state of charge, state of health, volts, amps, temperature, remaining life and fault data
- Local Time and Flight Timer (available)
- Night Vision Imaging System (NVIS) compatible (available)
- Fits standard 2-inch panel cutout
- Rechargeable, field-replaceable emergency battery (available)
- Lightweight — 0.4 lbs
- Simple user interface — Push-and-turn control knob
- Daylight readable LCD and smooth, high-resolution graphics
- External lighting control and built-in photocell for automatic dimming
- Field-upgradeable software via standard USB-A port
- TSO-certified hardware and software (Design Assurance Level A)
- Designed and built in Wichita, Kansas, USA
- Two-year limited warranty
Specifications
Power Input
10–32 VDC
0.14 A @ 28 VDC; 4 watts nominal
Data Input
ARINC 429
Data Output
ARINC 429
Battery
Rechargeable coin cell (memory only)
Rechargeable, field-replaceable emergency battery supply (available)
P/N 6430006-(1)
Technology: Nickel-Metal Hydride (NiMH)
Attributes: 0.25A @ 24 VDC nominal (6 Wh capacity)
Runtime: 60 minutes @ 0.25A
Weight
0.4 lbs (0.17 kg)
Mounting
Rear panel mounted, (4) #6–32 screws, 2.25-inch round bezel
Dimensions
2.43″W x 2.43″H x 1.0″D (61.7mm x 61.7mm x 25.4mm)
Mating Connector
P/N 9019162-1: 26-pin, D-Sub electrical connector (Quick Disconnect)
Certification
FAA TSO certified to C2d, C106, C113b
RTCA DO-160G qualified
RTCA DO-178C qualified, Design Assurance Level (DAL) A
Rights
U.S. Patent 11,048,389
